The ALTEA-412 passive system has been designed for use with external amplification and an outboard DSP. This allows users to choose the powering option they prefer and benefit from the same enclosure features and top-of-the-line components as the ALTEA 400 powered versions.



The ALTEA-412 uses the renowned 12Mi loudspeaker. This professional-grade loudspeaker provide precise low frequency reproduction with excellent musicality. The high frequencies are handled by the M-32 compression driver with 1″ exit to provide exceptional overall performance. A winning combination of matched components that offer ideal characteristics for music reproduction.



Features

2-way, full range system 12″ bass loudspeaker
1″ compression driver
Angled enclosure design for stage monitor use
Built-in rigging points
Stand mountable



Applications

Concerts and corporate A/V
Portable and live clubs
Concert halls, theaters and auditoriums
Houses of worship

DAS Altea-412 12" Passive Speaker (Single)

SKU: DASALTEA412
459,00 €Price
  • Frequency Range (-10 dB) 68 Hz - 20 kHz Net Weight kg 16.4 kg
    Audio Input Connector 1 x NL4 speakON Dimensions H x W x D (mm) 650 x 380 x 346 mm
    On-axis Sensitivity 1 W/1 m 96 dB SPL Finish Textured
    Nominal Impedance 8 ohms Color Black
    Peak Power Handling 1200 W Enclosure Material Polypropylene
    RMS Power Handling 300 W Maximum Peak SPL at 1 m 127 dB
    Dispersion 90? x 60? Audio Output Connector 1 x NL4 speakON
  • Performance
    Frequency Range (-10 dB) 68 Hz – 20 kHz
    Horizontal Coverage (-6 dB) 90º
    Vertical Coverage 60º
    Nominal Impedance 8 ohms
    RMS Power Handling 300 W
    Peak Power Handling 1200 W
    On-axis Sensitivity 1W/1 m 96 dB SPL
    Maximum Peak SPL at 1 m 127 dB
    Recommended Amplifier PA-900
    Recommended Processor DSP-226
    Connectors
    Audio Input Connector 1 x speakON NL4
    Audio Output Connector 1 x speakON NL4
    Enclosure
    Enclosure Construction Polypropylene
    Enclosure Geometry Trapezoidal
    Rigging M8 Rigging Points
    Color Black
    Depth 350 mm (13,8 in)
    Dimensions ( H x W x D ) 655 x 380 x 350 mm
    25,8 x 15,0 x 13,8 in
    Net Weight 14,5 kg ( 32,0 lb )
    Components
    LF Driver 12MI
    HF Driver M-32
    Shipping
    Carton Dimensions ( H x W x D ) 750 x 450 x 415 mm
    29,5 x 17,7 x 16,3 in
    Shipping Weight 17,5 kg ( 38,6 lb )
