The Fonestar FS2601E is a professional-grade slave amplifier built to deliver robust performance and reliable operation in various sound reinforcement systems.



Features:



Exceptional Power Handling: Boasts a maximum power output of 700 watts and a continuous RMS power output of 600 watts, ideal for driving multiple speakers in large venues.



Versatile Speaker Compatibility: Works seamlessly with a wide range of speaker impedances (4 and 8 ohms) and can handle both 100V and 70V speaker lines, making it suitable for distributed audio setups.



Comprehensive Protection Suite: Integrated protection circuits safeguard the amplifier against temperature spikes, short circuits, and overload conditions, ensuring long-lasting reliability.



Balanced Connectivity: Features two balanced auxiliary line inputs with XLR and 6.3mm jack connectors, offering a high input impedance of 20,000 ohms for clear and balanced audio transmission.



Wide Frequency Response: Delivers a faithful reproduction of sound across a broad frequency range of 50-22,000 Hz, ensuring accurate audio representation.



Visual Monitoring: LED indicators provide real-time status updates on temperature, protection activation, signal peaks, and output signal presence for informed operation.



Automatic Input Compression: Automatically regulates the input signal to prevent clipping and distortion, maintaining optimal audio quality.



Efficient Cooling System: The variable-speed forced ventilation system keeps the amplifier cool even under demanding use, ensuring reliable performance.



Standard Rackmount Design: Fits conveniently into a standard 2U 19-inch rack enclosure for professional integration into your sound system.

FONESTAR FS2601E - 600w Mono Slave Amplifier with 4ohm, 8ohm & 100v Line Output

SKU: FS-2601E
€999.95Price
    • FEATURES: Mono power amplifier.
    • POWER: 700 W maximum, 600 W RMS
    • RESPONSE: 50-22,000 Hz ±3 dB
    • DISTORTION: Harmonic: < 0.5%
    • INPUTS: 1 balanced aux line, XLR and 6.3 mm jack 20,000 Ω, 1 V RMS
    • OUTPUTS: 1 balanced aux line, XLR and 6.3 mm jack
    • FUNCTIONS: Forced ventilation with variable speed according to the temperature, Automatic compression of the input signal, LED for temperature, protection, signal peak and output signal indicators
    • PROTECTION: 3 circuits: temperature, short circuit and overload, Switches on smoothly., RF filter 500 kHz - 80 MHz
    • CONTROLS: Tone: bass, mid and treble ±12 dB, General volume
    • IMPEDANCE: 4 and 8 Ω and 100 and 70 V lines, screw terminals and banana plugs
    • POWER SUPPLY: 230 V AC, 1,000 W maximum, Resettable 6 A fuse
    • DIMENSIONS: 483 x 89 x 435 mm depth. 2 U 19" rack
    • WEIGHT: 17 kg
